NewBeeDrone Whirligig V2 Frame 3” 4” 5”

Introducing the Whirligig V2 Frame! This improved version is lighter while sacrificing no durability; easy to service while sacrificing no sophistication. Near perfect center of gravity with DJI Air Unit and stack on board. Extremely versatile so you can build it however you like: analog or HD (fits both DJI Air Unit or Caddx Vista Unit); whoop board or 20×20 stack; 3” 4” 5” arms – the combination is endless – even long range light weight build.

Design to work best with 1404 3000kv motors, 850mah 4s and a 20×20 FC and ESC stack for ~ 15 minutes flight time!

The 20×20 used on this frame must use M3 hardware.

• Slotted M3 stack mounting holes on the bottom plate
• DJI mounts in center of quad near CoG in the NBD DJI AirUnit Standoffs, M3 stack mounts in rear of quad suggested use of wire pcbs for shorter motor wires.
• frame can be used without DJI Air unit
• DJI Camera Mounting holes: M2 Mounting slots DJI Camera that allow for 10-40deg of cam angle
• A single M2 mounting hole for traditional micro cam mounting option.

Build Video:

FreeSytle Video:

Related Video:

Recommend Build List:

LongRange 4inch with DJI HD DVR

1x Whirligig V2 4inch Frame

1x NewBeeDrone Infinity200 Stack



Or

1x NewBeeDrone Cricket200 Stack



4x NewBeeDrone Flow 1404 3000KV Motors

1x DJI FPV AirUnit- Ultra low latency 720p 120fps digital HD

1x XT30 Lipo Pigtail 16AWG

1x Gemfan 4024 Hurricane Durable 2 Blade 1.5mm

1x TBS M8-2 GPS Module

LongRange 4inch with Vista Unit
Hardware:

1x Whirligig V2 4inch Frame

1x NewBeeDrone Infinity200 Stack



 Or

1x NewBeeDrone Cricket200 Stack



4x NewBeeDrone Flow 1404 3000KV Motors

1x Caddx Vista with DJI FPV Camera

1x XT30 Lipo Pigtail 16AWG

1x Gemfan 4024 Hurricane Durable 2 Blade 1.5mm

1x TBS M8-2 GPS Module

LongRange 5inch with DJI HD DVR

1x Whirligig V2 5inch Frame

1x NewBeeDrone Infinity200 Stack



 Or

1x NewBeeDrone Cricket200 Stack



4x NewBeeDrone Flow 2004 2450KV Motors

1x DJI FPV AirUnit- Ultra low latency 720p 120fps digital HD

1x XT30 Lipo Pigtail 16AWG

1x Gemfan 5125 Hurricane Durable 3blade 1.5mm

1x GNB 850mAh 4S Battery

1x TBS M8-2 GPS Module

LongRange 5inch with Vista Unit

1x Whirligig V2 5inch Frame

1x NewBeeDrone Infinity200 Stack



 Or

1x NewBeeDrone Cricket200 Stack



4x NewBeeDrone Flow 2004 2450KV Motors

1x Caddx Vista with DJI FPV Camera

1x XT30 Lipo Pigtail 16AWG

1x Gemfan 5125 Hurricane Durable 3blade 1.5mm

1x GNB 850mAh 4S Battery

1x TBS M8-2 GPS Module

Battery:

GNB 650mAh 4S battery

GNB 750mAh 4S battery

GNB 850mAh 4S Battery

3D Print Parts:

GoPro Hero8 3D File

Frame 3D Print Parts

Go2 Mount 3D file

Other 3D printed Parts design by Jason

Buy the 3D printed

Go2 Mount

Carbon Fiber Parts:
Body: Top Plate& Bottom Plate with Battery pad
Side Camera Plate
3inch Arm set include front and rear arm
OR
4inch Arm set include front and rear arm
OR
5inch Arm set include front and rear arm

Hardware include:
Standoff M2 25mm X2
Standoff M2 20mm X4
Screw M3 8mm X5
Screw M3 6mm X7
Screw M2 8mm X14

3D Printed parts
Left DJI AirUnit Antenna Mount
Right DJI AirUnit Antenna Mount
Back Caddx Vista Antenna Mount
GPS + back antenna Mount

Parts for the Whirligig V2
