SPECIFICATION

• Model: Caddx Ant
• Image Sensor: 1/3″ CMOS Sensor
• Horizontal Resolution: 1200 TVL
• TV System: NTSC or PAL
• MENU: Support
• IMAGE: 16:9 or 4:3
• Synchronization: Internal
• Electronic Shutter: PAL: 1/50~100,000; NTSC: 1/60~100,000
• S/N Ratio: >52dB (AGC OFF)
• Video Output: CVBS
• Lens: 1.8mm
• Min. Illumination: [email protected]
• Auto Gain Control: YES
• BLC: YES
• WDR: Global WDR
• DNR: 3D DNR
• Dimensions: 14*14mm(with bracket to 19*19mm)
• Wide Power Input: DC 3.7-18V
• Work Temperature: -20-60°C
• Work Humidity: 20%~80Caddx Ant 16:9 Silver
• Weight: 2g (N.W.)

INCLUDES

• 1 x Ant FPV Camera
• 1 x 3pin FPV silicone cable
• 1 x Warranty card
• 1 x Expend bracket
• 4 x Screws
